5Ton Textile Industry Special Electric Towing Tractor
5Ton Textile Industry Special Electric Towing Tractor 5Ton Textile Industry Special Electric Towing Tractor
5Ton Textile Industry Special Electric Towing Tractor 5Ton Textile Industry Special Electric Towing Tractor
5Ton Textile Industry Special Electric Towing Tractor 5Ton Textile Industry Special Electric Towing Tractor
5Ton Textile Industry Special Electric Towing Tractor 5Ton Textile Industry Special Electric Towing Tractor

loading

5Ton Textile Industry Special Electric Towing Tractor

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • WELIFTRICH

  • 12months

  • Jiangsu, China

  • 1420*780*1500mm

  • 780kg

  • 140mm

  • Electric Towing Tractor

  • 5ton

Availability:
Quantity:

Product Description

Quick Details:

Load capacity: 5000kg

Towing capacity: 8000kg

Max. rated tractive force: 750N

Travel speed, unladen/laden: 5/4.5km/h

Turning radius: 1500mm

Battery: 24V/210AH


Advantages:

     Standing type tow tractor.

      AC electronic controller

  • Special for textile factory.

  • Stepless speed regulation acceleration system.

  • Emergency braking function.

  • Built in charger.

  • Running brake and parking brake with big torque electromagnetic brake.

Specification



Model designation


ETT-50F

Characteristics


Power unit


electric



Lifting capacity

(kg)

5000



Towing capacity

(kg)

8000



Wheelbase

y(mm)

1155

Weights


Service weight(with battery)

kg

780

Wheels


Tyre,operator/load side


PU



Tyre size,load

mm

Φ112×100



Tyre size,drive

mm

Φ230×75



Auxiliary wheel size

mm

Φ130×55



Wheels number,front/back(x=driven)


2/1X+2



Tread, load

b11(mm)

337

Dimensions


Overall height

h15

1500



Lift height

h3(mm)

140




h13(mm)

120



stand height

h7(mm)

185



Overall length

l1(mm)

1420



Overall width

b1(mm)

780



Fork spread

b5(mm)

480



Ground clearance,centre of

m2(mm)

68



Turning radius

Wa(mm)

1500

Performances


Travel speed,with/without load

km/h

7/8



Lifting speed,with/without load

mm/s

41/54



Lowering speed,with/without load

mm/s

54/45



Max. climbing ability,with/without load(S2-5min)

%(tanθ )

10/12



Service brake


electronmagnetic

Drive


Drive motor rating(S2-60 min)

kw

2.2(AC)



Lift motor rating(S3-15%)

kw

2.2(DC)



Battery voltage/rated capacity

V/Ah

24/210



Battery weight


210



Steering System

kg

mechanical

Others


Battery replaces


hang up/sideway

Drawings

drawing1

drawing2
